Product Details:
Payment & Shipping Terms:
|
| Type:: | Packing Machine | Application: | Food,daily Chemical Etc |
|---|---|---|---|
| Automatic Grade:: | Automatic | Dimension(L*W*H):: | 2000*1200*2400MM |
| Additional Function: | Hanging Hole,special Shape | Bag Shape:: | Zipper Bag/doypack |
| High Light: | automatic packaging machine,packing machine for food products |
||
CE Approval Automatic Powder Bag Rotary Packing Machine With Vaccum
Features:
1. This machine adopts Intermittent working style, the hole-plate filling system. With whole-close system of the filling and rotary, easy for clean.
2. Up&Down module one-way movement, the imported double-lip Polyurethane sealing ring making good sealing performance.
3. Module cleaning station with the air blowing and sucking function, to protect the hole module without any powder under the high working condition.
4. Locking station with the powder sucking function
5. Finished capsule station with the Card capsule circle device, no powder flying.
Performance:designed for standup pouch with side spout packing. It can make standard standup pouches also with zipper, top spout as well as adding special functions like hanging hole or special shapes. Too add special functions to the pouches , please refer to DS-180SZ (zipper), DS-180SC(top spout) etc.
Technical parameters :
| Pouch Width | 90-180mm |
| Pouch Length | 180-260mm |
| Max Filling Capacity | 1000ml |
| Speed | 40-60 pouches per minute |
| Electric Components Brand | Mitsubishi/Schneider/Simens |
| Touch Screen Language | English/Spanish/Russia |
| Electricity Consumption | 9KW |
| Air Consumption | 250 NL/min |
| Weight | 2500kg |
| Size (L×W×H) | 6600x1100x1500mm |
