Product Details:
Payment & Shipping Terms:
|
| Product Name: | High Speed Blister Packing Machine | Output: | Max.30cutting/min |
|---|---|---|---|
| Max. Forming Area And Depth: | 250*120*15 | Mould Cooling: | 60-100L/h |
| Weight: | 1700kg | Capacity Of Air Compressor: | 0.6-0.8Mpa ≥0.5m3/min |
| High Light: | Blister Packaging Equipment,Pharma Blister Packaging Machine |
||
Description
1. Travel scope can be adjusted.
2. Alu Alu Blister Packaging is available for this machine.
3. Mould is located by locating groove which makes it easy to change mould. The machine heats the PVC through conduction and forms it through pressing and frothing.
4. The material is fed automatically. The mould and feeder can be designed as user’s requirements.
5. Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmable controller, it can synchronize accurately.
6. Adopt the equipment of trace pressing, batch number printing and scarp-collecting.
7. Stepping motor Pulling Material more accuracy and easy adjusting
8. The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machine’s life.
Applications
· Currently the fastest Blister Machine in China; it is the culmination of over 20 years professional experience.
· The machine accommodates forming material reels of up to 600mm in diameter and a waste material trimming cutter, which allow production runs of approximately 90 minutes therefore reducing the material replacement frequency.
· Equipped with integrated forming material splicer to enhance efficiency.
· Automatic format positioning system achieves straightforward format changeover.
· Window frame type no-waste-trimming cutter saves packaging materials.
· Adopts transverse cutter which easily collects its blister card and rejects faulty blister.
· Can be connected to subsequent machines, e.g. High-Speed Cartoners, to form a whole pharmaceutical packaging line.
Specifications
| Double Function | ALU-PLASTIC-ALU | ALU-PLASTIC | |
| Cutting Frequency(ideal sizes:80*57mm) | 15-30 cutting/min | 20-45 cutting/min | |
| Max. Forming Area and Depth | 250×120×15mm | 250×120×15mm | |
| Adjustable Scope of Travel(mm) | 30-120mm | 30-120mm | |
| Packaging material(I.D.Φ75) | PVC(mm) | (0.15-0.4)×260×(Φ400) | (0.15-0.4)×260×(Φ400) |
| PTP(mm) | (0.02-0.15)×260×(Φ250) | (0.02-0.15)×260×(Φ250) | |
| Alu Alu Foil | (0.10-0.12)×260×(Φ400) | ||
| Paper(mm) |
(50-100)g/㎡ ×260×(Φ300) |
||
| Power | 380V 50Hz 11.5kw | 380V 50Hz 8.5kw | |
| Air compression(self-prepared) |
0.6-0.8Mpa≥0.5m³/min
|
||
| Recycle water or circulating water consumption |
60-100L/h
|
||
| Overall Dimension(L*W*H)(including foundation) |
4450×800×1600
|
||
| Dimension of Each Part |
1400×800×1600(front)
|
||
|
1650×800×1450(middle)
1400×800×1450(back)
|
|||
| Weight | About 1700kg | ||
Package
